Subsea Force Reingrid Subsea Pipeline Reinforced Mesh
Galvanized Wire Pipeline Reinforced Mesh Description:
Pipeline Reinforced Mesh also known as pipeline reinforcement mesh, pipeline mesh, marine reinforcement mesh, etc., is a welded mesh commonly used for the reinforcement of concrete counterweight coated pipelines. Marine reinforcement mesh is a popular product in the world industry and is used for concrete counterweight coating of offshore oil and gas pipelines. Marine reinforcement mesh is suitable for compression and impact coating processes. The diameter wires are deeply curled to facilitate the application of concrete coating. The material used is galvanized mild steel. It can be cold-dip galvanized iron wire or hot-dip galvanized wire deeply curled to facilitate application in concrete. Three specifications of marine reinforcement mesh are available with traditional 10 wire, 8 wire or 6 wire mesh systems. Pipeline reinforcement mesh is mainly used for concrete counterweight coating of submarine pipelines. In addition to conventional specifications, we also supply other specifications that can be customized according to customer requirements
Galvanized Wire Pipeline Reinforced Mesh Specification:
| Product Name |
Eight Lines Galvanized Wire CWC Pipeline Reinforced Mesh
|
| Material |
Galvanzied wire |
| Wire diameter |
2.0mm/2.2mm/2.4mm/2.7mm etc. |
| Mesh Hole size |
25.4mm x 67mm |
| Width dimensions |
190.5mm |
| Length dimensions |
140m/280m |
| Exposed Wire Edge |
≤ 2.5 mm |
| Roll Diameter |
700mm-1150mm |
| Technique |
Point Welded |
|
Ref Number
|
Main Wire
(mm)
|
Cross Wires
(mm)
|
Roll Width
Dimensions
(mm)
|
Roll Length
Dimensions
(mm)
|
|
CWC20
|
2.0@25.4
|
2.0@67
|
190.5
|
140/280
|
|
CWC22
|
2.2@25.4
|
2.2@67
|
190.5
|
140/280
|
|
CWC24
|
2.4@25.4
|
2.4@67
|
190.5
|
140/280
|
|
CWC27
|
2.7@25.4
|
2.7@67
|
190.5
|
140/280
|
Galvanized Wire Pipeline Reinforced Mesh Advantage:
l High quality material wire
l Standard wire diameter and hole size
l Enough roll width and roll length
l High tensile strength
l Strong anti-corrosion, anti-rust
l Strong welded point
l High degree of flexibility
l Long service life
l Easy to install
l Cost savings
Galvanized Wire Pipeline Reinforced Mesh Usage:
• Offshore oil and gas pipelines
• Subsea and underwater pipelines
• Underground water supply / drainage pipelines
• Concrete weight coating reinforcement
• Coastal and marine engineering pipeline protection
Our Company Information:
Hebei Reinforce Pipeline Mesh Co., Ltd is an enterprise focusing on deep-sea energy pipeline protection. It is located at No.6, Ruilian Industrial Zone B, Shuguang East Street, Xicheng Industrial Zone, Raoyang County, Hengshui City, Hebei Province. Our company takes the steel wire mesh for concrete weight coating of submarine oil and natural gas pipelines independently developed and produced as its core product, providing high-reliability protection solutions for global offshore oil and gas projects, and helping the safe operation and maintenance of energy infrastructure.
Product Tags:
|
|
Subsea Force Reingrid Subsea Pipeline Reinforced Mesh Images
|
